ball clay

The tradition & historical record

Ball clays are kaolinitic sedimentary clays that commonly consist of 20–80% kaolinite, 10–25% mica and 6–65% quartz, along with small amounts of organic matter (such as lignite) and trace amounts of other minerals such as pyrite and siderite. They are a common raw material for various types of ceramics, where their primary roles are to impart unfired strength, plasticity or to aid rheological stability during the shaping processes. Most ball clays impart colours ranging from buff to cream to off-white when fired in an oxidising atmosphere. The name "ball clay" is derived from the form of the extracted material when dug by spade as cubes, which then became rounded during subsequent transport, in Dorset and Devon, England during the early days of the industry during the 18th century. In 2008, UK production of ball clay was reported to be worth £82 million, with sanitaryware manufacturers being the largest single group of end users, representing 40% by volume. ¹

Deposits are relatively scarce due to the combination of geological factors needed for their formation and preservation. Commercial extraction of ball clays is undertaken across the world, including: ¹

Argentina (San Julian area of Patagonia) Brazil (various locations including the region around São Paulo – São Simão, Suzano and Ribeirão Pire) China (various including Guangdong Province) Czech Republic (Cheb, Plzeň, Prague, Most, S. Bohemia and W. Moravia) Germany (various locations but the main is the Westerwald region) Indonesia (various locations including the island of Kalimantan) Thailand (Lampang) United Kingdom (the Bovey Basin of south Devon, the Petrockstow Basin in north Devon and the area around Wareham in south-east Dorset) USA (Kentucky, Tennessee and Texas) ¹

Global production of ball clay by country for 2002–2003 was estimated to be: ¹

Some selected typical properties of various UK ball clays are: ¹

The ceramic use of ball clays in Britain dates back to at least the Roman era. More recent trade began when a clay was needed to make tobacco pipes in the 16th and 17th century. In 1771 Josiah Wedgwood signed a contract for 1,400 tons a year of ball clay with Thomas Hyde of Purbeck, enabling the production of thinner-walled ceramics. ¹

The text above is adapted from the Wikipedia article “Ball clay”, available under the Creative Commons Attribution-ShareAlike 4.0 licence. ¹

ball clay is kaolinitic sedimentary clay, according to the structured record cited below. This entry was generated automatically from that record and has not yet been reviewed by a person familiar with the tradition. ²

The source record links this tradition to 7 external registers, which can be verified through the citation. ²
