stone carving

The tradition & historical record

Stone carving is an activity where pieces of rough natural stone are shaped by the controlled removal of stone. Owing to the permanence of the material, stone work has survived which was created during our prehistory or past time. Work carried out by paleolithic societies to create stone tools is more often referred to as knapping. Stone carving that is done to produce lettering is more often referred to as lettering. The process of removing stone from the earth is called mining or quarrying. Stone carving is one of the processes which may be used by an artist when creating a sculpture. The term also refers to the activity of masons in dressing stone blocks for use in architecture, building or civil engineering. It is also a phrase used by archaeologists, historians, and anthropologists to describe the activity involved in making some types of petroglyphs. ¹

The earliest known works of representational art are stone carvings. Often marks carved into rock or petroglyphs will survive where painted work will not. Prehistoric Venus figurines such as the Venus of Berekhat Ram may be as old as 250,000 years, and are carved in stones such as tuff and limestone. These earliest examples of the stone carving are the result of hitting or scratching a softer stone with a harder one, although sometimes more resilient materials such as antlers are known to have been used for relatively soft stone. Another early technique was to use an abrasive that was rubbed on the stone to remove the unwanted area. Prior to the discovery of steel by any culture, all stone carving was carried out by using an abrasion technique, following rough hewing of the stone block using hammers. The reason for this is that bronze, the hardest available metal until steel, is not hard enough to work any but the softest stone. The Ancient Greeks used the ductility of bronze to trap small granules of carborundum, that are naturally occurring on the island of Milos, thus making a very efficient file for abrading the stone. ¹

The development of iron made possible stone carving tools, such as chisels, drills and saws made from steel, that were capable of being hardened and tempered to a state hard enough to cut stone without deforming, while not being so brittle as to shatter. Carving tools have changed little since then. Modern, industrial, large quantity techniques still rely heavily on abrasion to cut and remove stone, although at a significantly faster rate with processes such as water erosion and diamond saw cutting. One modern stone carving technique uses a new process: The technique of applying sudden high temperature to the surface. ¹

Carving stone into sculpture is an activity older than civilization itself. Prehistoric sculptures were usually human forms, such as the Venus of Willendorf and the faceless statues of the Cycladic cultures. Later cultures devised animal, human-animal and abstract forms in stone. The earliest cultures used abrasive techniques, and modern technology employs pneumatic hammers and other devices. But for most of human history, sculptors used hammer and chisel as the basic tools for carving stone. The process begins with the selection of a stone for carving. Some artists use the stone itself as inspiration; the Renaissance artist Michelangelo claimed that his job was to free the human form trapped inside the block. Other artists begin with a form already in mind and find a stone to complement their vision. The sculptor may begin by forming a model in clay or wax, sketching the form of the statue on paper or drawing a general outline of the statue on the stone itself. When ready to carve, the artist usually begins by knocking off large portions of unwanted stone. This is the "roughing out" stage of the sculpting process. For this task they may select a point chisel, which is a long, hefty piece of steel with a point at one end and a broad striking surface at the other. A pitching tool may also be used at this early stage; which is a wedge-shaped chisel with a broad, flat edge. The pitching tool is useful for splitting the stone and removing large, unwanted chunks. Those two chisels are used in combination with a masons driving hammer. Once the general shape of the statue has been determined, the sculptor uses other tools to refine the figure. A toothed chisel or claw chisel has multiple gouging surfaces which create parallel lines in the stone. ¹

Stone has been used for carving since ancient times for many reasons. Most types of stone are easier to find than metal ores, which have to be mined and smelted. Stone can be dug from the surface and carved with hand tools. Stone is more durable than wood, and carvings in stone last much longer than wooden artifacts. Stone comes in many varieties and artists have abundant choices in color, quality and relative hardness. Soft stone such as chalk, soapstone, pumice and Tufa can be easily carved with found items such as harder stone or in the case of chalk even the fingernail. Limestones and marbles can be worked using abrasives and simple iron tools. Granite, basalt and some metamorphic stone is difficult to carve even with iron or steel tools; usually tungsten carbide tipped tools are used, although abrasives still work well. Modern techniques often use abrasives attached to machine tools to cut the stone. Precious and semi-precious gemstones are also carved into delicate shapes for jewellery or larger items, and polished; this is sometimes referred to as lapidary, although strictly speaking lapidary refers to cutting and polishing alone. When worked, some stones release dust that can damage lungs (silica crystals are usually to blame), so a respirator is sometimes needed. ¹

Basic stone carving tools fall into five categories: ¹

Percussion tools for hitting - such as mallets, axes, adzes, bouchards and toothed hammers. Tools for rough shaping of stone, to form a block the size needed for the carving. These include feathers and wedges and pitching tools. Chisels for cutting - such as lettering chisels, points, pitching tools, and claw chisels. Chisels, in turn, may be handheld and hammered or pneumatic powered. Diamond tools which include burrs, cup wheels, and blades mounted on a host of power tools. These are used sometimes through the entire carving process from rough work to the final finish. Abrasives for material removals - such as carborundum blocks, drills, saws, grinding and cutting wheels, water-abrasive machinery and dressing tools such as French and English drags. More advanced processes, such as laser cutting and jet torches, use sudden high temperature with a combination of cooling water to spall flakes of stone. Other modern processes may involve diamond-wire machines or other large scale production equipment to remove large sections of undesired stone. The use of chisels for stone carving is possible in several ways. Two are: ¹

The mason's stroke, in which a flat chisel is used at approximately 90 degrees to the surface in an organized sweep. ¹

The text above is adapted from the Wikipedia article “Stone carving”, available under the Creative Commons Attribution-ShareAlike 4.0 licence. ¹

stone carving is art of shaping stone materials, according to the structured record cited below. This entry was generated automatically from that record and has not yet been reviewed by a person familiar with the tradition. ²

The source record links this tradition to 18 external registers, which can be verified through the citation. ²
